FT25
on Line After-Service
1 Year
Not Adjustable
Telescopic Forklift
Diesel Engine
1T - 5T
Diesel
500mm
>5000mm
New
Free Spare Parts
High Quality Price
3000kg
1 Year
400mm
Chinese Engine/Japanese Engine
Provided
6200mm
5730*2390*2485mm
125mm
Provided
Motor, Pump, Gearbox, Engine
5 Ton Specifications 5 Ton Forklift
1250mm
1070mm
TDER
Nude Packing, Fix in Container
5730*2390*2485mm
Fujian, China
Product Description
Uses: unloading and short-distance transportation of building materials, direct delivery of building materials to the operating
point, or feeding of truck cranes and tower cranes;
handling and site cleaning of various materials on the construction site;
using hoppers to transport bulk materials and level the ground; use high altitude Work platforms are installed at high altitude;
glass suction cups are used to install curtain walls;
various materials are transported on rough ground;
grass bales are transported in the pasture, feed is chopped, grass feed, and feces are cleaned.
point, or feeding of truck cranes and tower cranes;
handling and site cleaning of various materials on the construction site;
using hoppers to transport bulk materials and level the ground; use high altitude Work platforms are installed at high altitude;
glass suction cups are used to install curtain walls;
various materials are transported on rough ground;
grass bales are transported in the pasture, feed is chopped, grass feed, and feces are cleaned.
FT25/FT30 Mini Telescopic Forklift specification | ||||||||
No. | Description | Unit | ||||||
1 | Model | FT25/FT30 | ||||||
2 | Rated capacity | Kg | 2500/3000 | |||||
3 | Length | withuot forks | mm | 2920 | ||||
4 | with forks | mm | 4000 | |||||
5 | width | Frame width | mm | 1300 | ||||
6 | Height | Overhead Guard | mm | 2170 | ||||
7 | Max.lifting | mm | 4600 | |||||
8 | Axle distance | mm | 1850 | |||||
9 | Front overhang distance | mm | 570 | |||||
10 | front wheel distance | mm | 990 | |||||
11 | Rear wheel distance | mm | 990 | |||||
12 | Ground clearance | under mast | mm | 130 | ||||
13 | under wheelbase | mm | 190 | |||||
14 | Max. lifting height | mm | 4000 | |||||
15 | Free lifting height | mm | 3800 | |||||
16 | Max. horizontal reach | mm | 2090 | |||||
17 | Operation Weight | Kg | 4350/4500 | |||||
18 | Min. Turning Radius | mm | 2800 | |||||
19 | Max. Travelling Speed Without/load | km/h | 20 | |||||
20 | Max. Travelling Speed Full Loaded | km/h | 20 | |||||
21 | Load Center | mm | 500 | |||||
1.The FT30 Telescopic Forklift can do more than a conventional forklift with mast doing. It bring cost saving in term of using time, fuel, manpower and field occupancy.
2. It adopts many advanced technology on diesel engine design and manufacturing process independently developed
by the company. It is highly appraised by users. It has reliable quality, easy to start in winter, fuel
saving, compact structure, easy to maintain. It comply to Euro stage III emission requirement.
3. Unique CAE technology is used to obtain the optimal muffler volume and use sound proof material to reduce noise. Indirect jet engines, clean exhaust, meet the requirements of European III and EPA III emission regulations.
4.You can take advantage by using the Telescopic Forklift while load and unload the truck/trailer from only one side, that will occupy half of yard loading space; You can use the rest of the load space for other tasks without spending extra time relocating vehicles around the workplace.
5.Telescopic forklift fitting sand compatibility with a variety of industry-specific accessories give you great flexibility and the ability to work in a variety of applications.
6. The telescopic boom allows single-sided loading, which can be extended to the far side of the railway truck across the platform gap, to reaching the inside of the truck, or load cargo in ships across the dock.
7. With side open doors and tilting cab, all major components and maintenance intervals can be inspected quickly and easily on the ground. Operator's routine check point is behind the side door.
8.The indicator to fuel tank is easy to identify. Dashboard is simple, versatile and easy to read.
Certification we have
After-services: TIDER industrial is committed to offer not only products with high quality and performance and competitive price, but also in-time delivery and comprehensive after-services. All the products purchased from Tider enjoy one year or 2000 hours (which occurs first) warranty. During the warranty period, if there is any part broken because of quality problem (except easy-damaged parts), the defective parts will be repaired or replaced free of charges.
1. Why choose us?As a manufacturer, Tider industrial is committed to offer not only products with high quality and performance and competitive
price, but also in-time delivery and comprehensive after-services.
2. What is the product range of our factory ?
Tider industrial is a large-scale machinery manufacturing enterprise primarily specializes in supplying wheel loaders, forklift
trucks and related attachments. We can also customize non-standard products according to customer's requirements.
3. What payment terms can we accept?
Normally 30% deposit is required in advance, 70% balance shall be settled before shipment. And 100% irrevocable L/C at sight with
the terms we agreed can also be accepted.
4. What Certificates do we have?
All products meet with the ISO9001 Quality System and have acquired CE certificate. EPA approval will be available if needed.
5. How about our delivery time?
Usually it will take 15 to 30 days after receiving your deposit. About standard products, we always have in stock and can deliver
immediately. But customized products will take more time, depending on the requirements of your order.
6. Can we provide OEM service?
Tider industrial can provide customized products according to customers' requirements, both OEM and ODM are acceptable.
price, but also in-time delivery and comprehensive after-services.
2. What is the product range of our factory ?
Tider industrial is a large-scale machinery manufacturing enterprise primarily specializes in supplying wheel loaders, forklift
trucks and related attachments. We can also customize non-standard products according to customer's requirements.
3. What payment terms can we accept?
Normally 30% deposit is required in advance, 70% balance shall be settled before shipment. And 100% irrevocable L/C at sight with
the terms we agreed can also be accepted.
4. What Certificates do we have?
All products meet with the ISO9001 Quality System and have acquired CE certificate. EPA approval will be available if needed.
5. How about our delivery time?
Usually it will take 15 to 30 days after receiving your deposit. About standard products, we always have in stock and can deliver
immediately. But customized products will take more time, depending on the requirements of your order.
6. Can we provide OEM service?
Tider industrial can provide customized products according to customers' requirements, both OEM and ODM are acceptable.
