All kinds of details perfectly clear display, three speed adjustable, easy to use
| project | parameter | |||
| Technical matter number | Car size (long X party X high) mm | 3400X1320X2140 (Si 50m) | normal voltage V | 60v |
| Vehicle size (long X party 2 high) mm | 2000X1200X1250(±10m) | Walking motor, power | Maintenance-free brushless motor of 2500W | |
| Count the weight of kg | 900 | Hydraulic motor power | 800T | |
| curb weight kg | 910 | Hydraulic oil pump noise | ≤10041 | |
| tread m | 980 | Vehicle lifting time | ≤13 | |
| wheel base m | 2320 | Turning bucket lifting time s (empty bucket) | ≤15 | |
| Vehicle effective volume # | ≥2.5m² | Drop time s (empty bucket) | ≤10 | |
| speed per hour km/h | Low speed 15, high speed 35 | Tyre size and requirements | Front 450-12, rear 500-12 | |
| endurance mileage km | 80km | Before the exhibition | Aggravated domestic and foreign oil pressure extension thread type iron reduction | |
| Single battery capacity, quantity | Lake brand type 180 water battery or optional maintenance-free battery, 5 | Front steering casing structure | The axial shaft casing wall is 4 mm thick | |
| Electric belt construction | Vehicle material structure | The front and rear and left and right side panels of the carriage are 1.5mm cold rolled plate, and the thickness of the bottom plate is 1.8mm.8 cm for waterproof sealing treatment | ||
| Sealing mode and buckle | The car is equipped with advance, the back door is equipped with sealing tape to prevent sewage leakage, the buckle is adjustable tightening buckle | |||
| Electric pull system | 60V36 tube dual-mode intelligent control | |||
| Control the way you walk | Turn the | |||
| Driving mode | Direction handle | |||
| brake system | The vehicle adopts the foot brake hydraulic brake system. Misoperate the power-off system | |||
| brake mode | Foot ball hydraulic effect-manual parking | |||
| Driving heavy materials and lamps | Steel structure, safety cab using mold stamping molding cold plate material. Front integrated song into LED headlights, injection molding instrument bench. With windshield wiper, warning light, cab foot pedal with leather board, flat pedal. | |||
| Cab structure | Overall ram cab " optional cab door). | |||
| Car door, wing benefit | The split type back door can be opened 270° upward, with a side door on one side of the bucket flip, and the lid is 1.2mm cold rolled plate. The opening mode of the upper cover is the side of the bucket pper, and the double adjustment lock is adopted with the door. | |||
| Harness assembly line mode | High and low voltage double line slightly: high temperature line high voltage 10 square, low voltage 1 square | |||
| Drive young bridge | Using load without chain full suspension belt high and low speed truck type rear bridge: large diameter cart drum, diameter 30mm thick half shaft, hydraulic drum type chop car. | |||
| The rear suspension | Two sets of main and auxiliary spring steel are used. Single group of 11 pieces, with auxiliary spring support, greatly improve the load capacity. | |||
| Oil pipe layout | Steel high pressure tubing and hose are used on the bucket track and fixed with a special pipe clip | |||
| The fine institutions | Limit mode of the bucket device | The bucket per falls to the bed limited pin. | ||
| hydraulic control valve | The micro-switch works synchronously with the oil pump, and the control valve is installed on the right side bucket in the cab. | |||
| Hydraulic control valve control mode | The hydraulic control valve with linkage switch works synchronously with the oil pump, | |||
| Bucbucket rail material and structure | The main track is the thickened steel pipe. The barrel guide wheel has-needle roller bearing. | |||
| Fixed mode of the bucket turning device | The bucket track is fixed on the carriage, and the bucket and the turning mechanism and the carriage are connected by separate speed | |||
| Turn over the bucket device | Upper type double cylinder, with lifting type 10m iron plate symmetrical hanger. Turn the bucket Angle 138'to make sure the garbage is clean. | |||
| Hanging bucket requirements | Supporting with gb 120L and 240-liter trash cans, | |||
| Hang the bucket to cover the pull rod | Is an adjustable and fixed type. | |||
| Turn over the bucket machine citrate | The outer diameter of the large shaft 34m inner diameter 24m seamless steel pipe shaft, the large shaft support pressure cover is the national standard 6 # sentiment steel | |||
| Turn over the barrel boom machine | There is an anti-deformation protection device, and the upper and lower end of the boom fixed pin shaft is of 8.8 level. | |||
| Hydraulic power unit | Connect with 60V DC motor and oil pump integrated. | |||
| The frame material | The girder adopts 80*40*3.5mm rectangular tube, and uses cathode electrophoresis to prevent the treatment. | |||
| Maximum recall slope | ≥15°. | |||
| The mode of the battery pack | The bucket pper is placed on the left, with a waterproof cover plate above the battery pack. | |||
| Types of cylinder configuration | The bucket flip machine uses single stroke double cylinder, and the car lifts use single stroke one-way thickened oil cylinder. | |||
| Layout mode of the oil pipeline road | Layranged on the side of the frame, not on the frame bed surface, to prevent some foreign body on the surface, | |||
1.Q: Can l get some samples?
Re: We are honored to offer you samples for quality check.
2.0: Do you have the products in stock?
Re: No, All products are to be produced according to your order including samples.
3. Q: When is the delivery time?
Re: lt usually takes about 25 working days to produce an order from MOQ to a 40HQ container.
But the exact delivery time might be different for different orders or at different times.
4.Q: can l mix different models in one container?
Re: Yes, different models can be mixed in one container, and the total quantity of each model should not be less than MOQ.
5.Q: How does your factory do regarding quality control?
Re: Quality is a priority. We always attach great importance to quality control from the very beginning to the end of production.
Every product will be fully assembled and carefully tested before it's packed for shipment.
6.Q: What's your warranty term?
Re: We offer different warranty times for different products. Please contact us for detailed warranty terms.
7. Q: Will you deliver the right goods as ordered? How can l trust you?
Re: Yes, we will. One of the core of our factory cultures is honesty and credit. LUBEI has never got any complaints from our customers.
8.Q: What is your payment?
Re: TT, LC. D/P
9.0: What are your shippingterms?
Re: EXW, FOB, CNF, CIF.
