| Model No. | TH704353 |
| Size | 16mm-135mm |
| Specification | 16-130mm |
| Delivery Time | 15-30days |
| Surface | Blacken/Self Colour |
| Processing | Welded Chains |
| Origin | China |
| Diameter | Size | U1 stud link anchor chain | U2 stud link anchor chain | U3 stud link anchor chain | Weight | |||||
| D(φ) | ||||||||||
| Outside length | Outside width | Proof load | Breaking load | Proof load | Breaking load | Proof load | Breaking load | 27.5M | ||
| L | B | |||||||||
| Inch | mm | mm | mm | KN | KN | KN | KN | KN | KN | KG |
| 1/2 | 12.5 | 75 | 45 | 46 | 66 | 66 | 92 | 92 | 132 | 98 |
| 9/16 | 14 | 84 | 50.4 | 58 | 82 | 82 | 116 | 116 | 165 | 119 |
| 5/8 | 16 | 96 | 57.6 | 76 | 107 | 107 | 150 | 150 | 216 | 156 |
| 11/16 | 17.5 | 105 | 63 | 89 | 127 | 127 | 179 | 179 | 256 | 186 |
| 3/4 | 19 | 114 | 68.4 | 105 | 150 | 150 | 211 | 211 | 301 | 230 |
| 13/16 | 20.5 | 123 | 73.8 | 123 | 175 | 175 | 244 | 244 | 349 | 260 |
| 7/8 | 22 | 132 | 79.2 | 140 | 200 | 200 | 280 | 280 | 401 | 300 |
| 15/16 | 24 | 144 | 86.4 | 167 | 237 | 237 | 332 | 332 | 476 | 370 |
| 1-1/16 | 26 | 156 | 93.6 | 194 | 278 | 278 | 389 | 389 | 556 | 431 |
| 1-1/8 | 28 | 168 | 100.8 | 225 | 321 | 321 | 449 | 449 | 642 | 496 |
| 1-3/16 | 30 | 180 | 108 | 257 | 368 | 368 | 514 | 514 | 735 | 564 |
| 1-1/4 | 32 | 192 | 115.2 | 291 | 417 | 417 | 583 | 583 | 833 | 635 |
| 1-5/16 | 34 | 204 | 122.4 | 328 | 468 | 468 | 655 | 655 | 937 | 712 |
| 1-7/16 | 36 | 216 | 129.6 | 366 | 523 | 523 | 732 | 732 | 1050 | 800 |
| 1-1/2 | 38 | 228 | 136.8 | 406 | 581 | 581 | 812 | 812 | 1160 | 887 |
| 1-9/16 | 40 | 240 | 144 | 448 | 640 | 640 | 896 | 896 | 1280 | 1032 |
| 1-5/8 | 42 | 252 | 151.2 | 492 | 703 | 703 | 981 | 981 | 1400 | 1084 |
| 1-3/4 | 44 | 264 | 158.4 | 538 | 769 | 769 | 1080 | 1080 | 1540 | 1197 |
| 1-13/16 | 46 | 276 | 165.6 | 585 | 837 | 837 | 1170 | 1170 | 1680 | 1310 |
| 1-7/8 | 48 | 288 | 172.8 | 635 | 908 | 908 | 1270 | 1270 | 1810 | 1438 |
| 2 | 50 | 300 | 180 | 686 | 981 | 981 | 1370 | 1370 | 1960 | 1546 |
| 2-1/16 | 52 | 312 | 187.2 | 739 | 1060 | 1060 | 1480 | 1480 | 2110 | 1661 |
| 2-1/8 | 54 | 324 | 194.4 | 794 | 1140 | 1140 | 1590 | 1590 | 2270 | 1791 |
| 2-3/16 | 56 | 336 | 201.6 | 851 | 1220 | 1220 | 1710 | 1710 | 2430 | 1926 |
| 2-5/16 | 58 | 348 | 208.8 | 909 | 1290 | 1290 | 1810 | 1810 | 2600 | 2086 |
| 2-3/8 | 60 | 360 | 216 | 969 | 1380 | 1380 | 1940 | 1940 | 2770 | 2249 |
| 2-7/16 | 62 | 372 | 223.2 | 1030 | 1470 | 1470 | 2060 | 2060 | 2940 | 2361 |
| 2-1/2 | 64 | 384 | 230.4 | 1100 | 1560 | 1560 | 2190 | 2190 | 3130 | 2516 |
| 2-9/16 | 66 | 396 | 237.6 | 1160 | 1660 | 1660 | 2310 | 2310 | 3300 | 2676 |
| 2-11/16 | 68 | 408 | 244.8 | 1230 | 1750 | 1750 | 2450 | 2450 | 3500 | 2885 |
| 2-3/4 | 70 | 420 | 252 | 1290 | 1840 | 1840 | 2580 | 2580 | 3690 | |
1.Our Shipyard:Ningbo Zhenhe shipyard, and now Taihang is the branch representative of our yard.
2.Our founding team has experience of more than 15 years in ship building and ship repair with our own engineer and designer.
3.Equipment quality guarantee: Based on shipyard feedback, we built up manufacturer file to ensure the good quality of the products. Also we can send our engineers to help our clients to install and test these exported equipment.
4.We are a second hand ship broker to help you find the satisfied used different kind vessels.
5.We are able to provide the CKD kits and one-stop service based on our laser-cutting machine and purchase ability
6. We have a very professional design and technical team to work out perfect plan for our clients and help to slove out any matters with pre-sale and after-sale.
7.Customer Distribution: Tananzia, Rwanda, India(Mumbai and Kalkatta), Suva, Portugal, Russia, Nertherland, Iceland, Denmark, Malaysia, Mexico.......
