FD50, FD60, FD70
Provided
1 Year
Not Adjustable
Diesel Forklift
Diesel Engine
1T - 5T
Diesel
500mm
3000~5000mm
New
Side Shifter
Diesel Forklift Truck
Customer Demanded
3000-4262mm
1 Year
Forklift Diesel 3 Ton 4 Ton Diesel Forklift
125mm
Secsun
Provided
Pump, Gearbox, Engine
Hydraulic System 3 Ton Diesel Forklift
1070mm
Forklift 3 Ton Diesel
Japanese Engine
Provided
SECSUN
Nude, Fix in Container
2600*1150*2055 mm
China
Product Description
| Model | FD50 | FD60 | FD70 | |
| Rated lifting load | kg | 5000 | 6000 | 7000 |
| Load center distance | mm | 600 | ||
| Free lifting height | mm | 210 | ||
| overall length (With fork/Without fork) | mm | 4690/3510 | 4720/3590 | 4810/3680 |
| Width | mm | 1970 | ||
| Overhead guard height | mm | 2500 | ||
| Wheelbase | mm | 2250 | ||
| Minimum ground clearance | mm | 230 | ||
| Mast tilt angle (front/rear) | % | 6° /12° | ||
| Tire no. (before) | 8.25-15-14PR | |||
| Tire no. (after) | 8.25-15-14PR | |||
| Minimum turning radius (outer side) | mm | 4080 | 4120 | 4180 |
| Minimum right angle aisle width | mm | 5230 | 5290 | 5360 |
| Fork size | mm | 1220*150*60 | 1220*150*65 | |
| maximum working speed(Full-load/No-load) | km/h | 24/29 | 23/29 | 22/29 |
| maximum lifting speed(Full-load/No-load) | mm/s | 510/530 | 500/530 | 500/480 |
| maximum gradeability(Full-load/No-load) | % | 15/20 | ||
| Forklift weight | kg | 8400 | 8900 | 9600 |
| Engine model | Quanchai4J1-115C32 | |||
OEM/ODM
Optional Attachment
Spare Parts
1. Why choose us?
A: We can offer you wide-range products like forklift, loader, excavator, skid steer loader, backhoe loader, road roller, motor grader, tractor, etc. So we can provide your ONE-STOP SERVICE during purchasing different products with high efficient.
2. What payment terms can we accept?
A: Normally 30% deposit in advance, 70% balance should be paid before shipment. And 100% irrevocable L/C at sight with the terms we agreed can also be accepted.
3. How long is your warranty?
A: One year or 2000 working hours which occurs first.
4. How about our delivery time?
A: Usually it will take 15 - 30 days after receiving your deposit. But for standard products, we always have in stock and can
deliver within 5 days.
5. Can we provide spare parts?
A: Yes, we can provide you the spare parts list if you need, welcome to contact us freely.
