High-quality marine portable gas detection equipment
The machine is a single gas detector with a high performance-price ratio. It adopts high-quality sensors and embedded MCU micro-control technology. It has fast response speed, high measurement accuracy, good stability, and repeatability. The performance of the machine is in the leading position in the industry.
Main Features
2) Adjustable low and high alarm level
3) Adjustable calibrating level
4) High-concentration protection for combustible gas
5) Self-test for the combustible gas sensor
6) Low battery indication
7) Replaceable sensor module
Alarm method | Audio, Visual LED and Vibratory | ||
Working environment | -20ºC~50ºC | ||
Power Supply | 3.7V Rechargeable lithium battery | ||
Gas Sensor Life | 2 years | ||
Charging time | Less than 5 hours | ||
Data record | 1000pcs data storage | ||
Working time | 8h continuously | ||
Password protection | Password protection and password modification | ||
Explosion-proof grade | Exib IIB T3 Gb | ||
Principle | Electrochemical and Catalytic sensor | ||
Additional function | Flashlight | ||
Humidity | 0-95%RH (no dew) | ||
Shell material | ABS | ||
Dimensions | 100*60*30mm(L*W*H) | ||
No. | Detected Gas | Detecting Scope | Resolution | Low/High Alarm Point | Response Time | Detection Accuracy |
1 | PH3 | 0-20ppm | 0.1ppm | 5ppm/10ppm | ≤25s | ±5%(F.S) |
2 | O2 | 0-30%vol | 0.1%vol | 19.5%vol/23.0%vol | ≤15s | ±5%(F.S) |
3 | EX | 0-100%LEL | 1%LEL | 25%LEL/50%LEL | ≤5s | ±5%(F.S) |
4 | CO | 0-1000ppm | 1ppm | 50ppm/100ppm | ≤25s | ±5%(F.S) |
5 | H2S | 0-100ppm | 1ppm | 10ppm/20ppm | ≤30s | ±5%(F.S) |
6 | NO2 | 0-20ppm | 0.1ppm | 3ppm/10ppm | ≤25s | ±5%(F.S) |
7 | NO | 0-250ppm | 1ppm | 25ppm/50ppm | ≤60s | ±5%(F.S) |
8 | SO2 | 0-20ppm | 0.1ppm | 5ppm/10ppm | ≤30s | ±5%(F.S) |
9 | CL2 | 0-20ppm | 0.1ppm | 1ppm/10ppm | ≤30s | ±5%(F.S) |
10 | NH3 | 0-100ppm | 1ppm | 25ppm/50ppm | ≤50s | ±5%(F.S) |
11 | H2 | 0-1000ppm | 1ppm | 50ppm/100ppm | ≤60s | ±5%(F.S) |
12 | HCN | 0-10ppm | 0.1ppm | 1ppm/5ppm | ≤200s | ±5%(F.S) |
13 | HCL | 0-10ppm | 0.1ppm | 1ppm/5ppm | ≤60s | ±5%(F.S) |
14 | CH4 | 0-100%LEL | 1%LEL | 25%LEL/50%LEL | ≤5s | ±5%(F.S) |
The detector is suitable for explosion-proof, toxic gas leakage and rescue, underground pipelines, mines, metallurgy, power plants, chemicals, tunnels, etc., effectively avoiding the occurrence of poisoning accidents, ensuring the safety of workers, and avoiding losses of production equipment.
1. Our Shipyard: Ningbo Zhenhe shipyard, and now Taihang is the branch representative of our yard.
2. Our founding team has experience of more than 15 years in shipbuilding and ship repair with our engineer and designer.
3. Equipment quality guarantee: Based on shipyard feedback, we built up a manufacturer file to ensure the good quality of the products. Also, we can send our engineers to help our clients to install and test this exported equipment.
4. We are a second-hand ship broker to help you find the satisfied used different kinds of vessels.
5. We can provide the CKD kits and one-stop service based on our laser-cutting machine and purchase ability
6. We have a very professional design and technical team to work out the perfect plan for our clients and help to solve any matters with pre-sale and after-sale.
7. Customer Distribution: Tanzania, Rwanda, India(Mumbai and Kolkata), Suva, Portugal, Russia, Netherlands, Iceland, Denmark, Malaysia, Mexico.......
