ND-4.5
Yes
1 Year
Customized
ISO9001
Railway Equipment
Stainless Steel
Two- Stroke Petrol Engine,1.6kw
4400 r.p.m
30~40 J
22 Hz
0.95 L
25 Kg
Linkage
840*470*350 mm
China
Product Description
Railway construction, ballast construction, single rail tamping machine, internal combustion shock absorption, tamping stone
ND-4 portable tamper is a special machine for ballast tamping on railway lines and turmouts. Choose high-vibration, high-power gasoline engine as power, with high output power and stable. performance. The air compression hammer impact pick is used to impact the ballat. The impact force is large and the tamping effect is good. The whole machin is smal in size, ight. in. weight, and convenient. to go up and down, which can ffectively guarantee driving safety during operation.
Model | ND-4 |
Type | Rail Tamper |
Material | Stainless Steel |
Dimensions (L x W x H) (mm) | 840*470*350 mm |
Engine | Two- stroke petrol engine,1.6kW |
Rated RPM | 4400 r.p.m |
Impact energy | 30~40 J |
Impact frequency | 22 Hz |
Fuel tank volume | 0.95 L |
Weight | 25 kg |
Selling Units:
Single item
Single package size:
95X60X45 cm
Single gross weight:
35.000 kg
Package Type:
Export Standard Wooden box + pe bag+paper carton, 1 unit/Wooden box , Wooden box:95*60*45 cmcm G.W: 35KG
We started our business from producing railway measurement device in 2003 and wide our product range to small rail machines like rail cutting machine ,rail grinding etc .
Our company has expanded its operation to include three branch office , location facilitates in Xiangyang ,Wuhan and Guangzhou China.
Now, Linkage family of brands provides a diverse and comprehensive product line for different markets and demands.
Our products are sold in more than 50 countries and regions worldwide.
Market acceptance is backed by ISO9001, European CE certification .
As a Chinese mainland based company, we like to take our advantage of low cost and strive to offer you quality products with most competitive pricing with integrity.
