Aircraft refueling vehicles refer to those special vehicles that provide refueling and pumping for aircraft at airports.
Unlike ordinary diesel and gasoline, many aircraft use aviation kerosene.
Aviation kerosene is corrosive to ordinary metals, so all the places where kerosene flows through, such as oil tanks, pipelines, pumps and fuel dispensers, should be protected against corrosion by stainless steel.
Aluminum 6180L Helicopter Aircraft Tanker (Aviation Kerosene, Gasoline, Jet Fuel Oil 1632US Gallon Refueler Aircraft Tanker)
1.The aircraft refueling trucks produced by our factory have a very bright market share at home and abroad, and have passed the EU ADR certification,High quality products and considerate service have been well received by customers at home and abroad.
2.The tank body is made of aluminum magnesium alloy 5083, with light deadweight, large volume, corrosion resistance and no pollution. The quality of oil products is guaranteed. The tank and pipeline are passivated to ensure that there is no impurities. and can issue tank inspection and flaw detection reports.
3.Meet the customer's personalized requirements for the vehicle. The upper mounting can be completely independent from the chassis to facilitate maintenance; Accessories can be installed according to customers' request.make the operator to refuel the aircraft simply, safely and efficiently.
Performance description:
1. Reel refueling: After filtering and metering, the fuel in the tank of the vehicle is injected into the aircraft fuel tank or other fuel receiving equipment through the gravity refueling gun of the reel hose in the control room.
2. Pump oil filtration: filter the fuel in the oil tank of the vehicle or in the external pipeline, and then return it to the oil tank of the vehicle or other oil receiving equipment through the pump outlet connector to realize the ball circulation filtration function.
3 .For oil tank loading, the external pipeline of the joint valve is used to load oil at the bottom of the oil tank, or the oil pumping function can be realized through this oil pump.
| Truck Chassis | ||
| Chassis | Brand | Dongfeng(IS-UZU/HOWO/FOTON in optional) |
| Wheelbase(mm) | 3950 mm | |
| Dimensions(mm) | 7300x2170x2410mm/5940*2000*2700mm | |
| Cab | Single row cabin, Allowable 3 passengers. With A/C in optional | |
| Transmission | 8F+1R | |
| Front/Rear Axle | 3900/8000 kg | |
| Tire | 7.00R16, 6pcs with one spare tire | |
| Engine | Model | CUMMINS B170 33 |
| Horsepower | 190HP | |
| Cylinder number | 4 cylinders in-line, 4-strokes, water-cooled | |
| Emission standard | Euro III, diesel | |
| Fuel Tank | ||
| Fuel tank | Capacity | 8500Liters |
| Tank material | Q235 high tensile strength steel | |
| Thickness | 5mm | |
| Compartment | Single Compartment (several compartments in optional ) | |
| Manhole cover | 1 manhole cover, with breather valve | |
| Safety Valve | equipped on the tank bottom | |
| Discharge valve | Aluminium Alloy Ball Valve type (stainless steel ball valve is optional) | |
| Oil Pump | Equipped | |
| Refuelling Dispenser | Equipped | |
| Emergency Cutoff Device | Equipped | |
| Standard | tool box,climbing ladder, handrail, fire extinguisher, oil hose etc are included | |
| Ladder | At rear of tank | |
| Painting | Color and design as customer's requirement | |
1. who are we?
We are based in Hubei, China, start from 2004,sell to South America(20.00%),Africa(20.00%),South Asia(10.00%),Eastern Asia(10.00%),Southeast Asia(10.00%),North America(10.00%),Eastern Europe(5.00%),Western Europe(5.00%),Mid East(5.00%),Northern Europe(3.00%),Central America(2.00%). There are total about 1000+ people in our office.
2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;
3.what can you buy from us?
Fire fighting truck,LPG tank trailer,Crane truck,Concrete Mixer Truck,Tanker truck
4. why should you buy from us not from other suppliers?
1.Truck manufacturer , quality guarantee . 2.Customer-made accepted 3.Lower price .
5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES;
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,Arabic,French,Russian,Korean,Hindi,Italian
