Model NO.
NDPJ-RBHQ-2
Thermal Protector Dimension
as Per Customer′s Drawing
Function
Prevent Motors From Damage
Open Temperature
Customized
Reset Temerature
Customized
Competitive Advantages
Variety of Application
Storage
Away From Other Humid Material
Transport Package
Pallet Suitable for Sea Transportation
Specification
customized
Trademark
NIDE
Origin
China
HS Code
8545200000
Production Capacity
10, 000, 000PCS/Year
BR-A2D. BW series thermal protector is an automatic temperature recovery device. It is installed in series with the motor coil. Therefore, the thermal protector will respond to the temperature change. The heat caused by temperature raise will transmit to bimetallic element. Once the preset temperature is reached, the bimetallic element will react and make contactor cut off. Then the circuit will be cut off. Once the motor temperature decreases to the rated recovery temperature, bimetallic element will recover to the initial station. Then the contactor will close and the circuit will reconnect.
Temperature specification
Open temperature: 50~150±5ºC, one gear per 5ºC
Reset temperature: it is 2/3 of standard opening temperature or specified by customers. The tolerance is 15ºC.
Contact capacity
They are applicable for more than 5000 cycles under following condition.
Storage
Keep the package material and the part itself from snow, rain and pressure. Air humidity should be less than 90%
Information needed for thermal protector inquiry
It will be better if customer could send us detailed drawing including below information.
1. Thermal protector dimension: length, height, width, tolerance, lead wire length.
2. Thermal protector open temperature
3. Thermal protector recovery temperature
4. Thermal protector applications
5. Required quantity
6. Other technical requirement.
Temperature specification
Open temperature: 50~150±5ºC, one gear per 5ºC
Reset temperature: it is 2/3 of standard opening temperature or specified by customers. The tolerance is 15ºC.
Contact capacity
They are applicable for more than 5000 cycles under following condition.
| Voltage | 24V-DC | 125V-AC | 250V-AC |
| Current | 12A | 12A | 8A |
Storage
Keep the package material and the part itself from snow, rain and pressure. Air humidity should be less than 90%
Information needed for thermal protector inquiry
It will be better if customer could send us detailed drawing including below information.
1. Thermal protector dimension: length, height, width, tolerance, lead wire length.
2. Thermal protector open temperature
3. Thermal protector recovery temperature
4. Thermal protector applications
5. Required quantity
6. Other technical requirement.
