Model NO.
A11D30
Customized
Customized
Transport Package
Carton
Trademark
xiyuan
Origin
China
HS Code
9031809090
Production Capacity
10000 Pieces/Year
Type:
Piezoelectric
Output Signal Type:
Analog Output
Measuring Shaft Quantities:
Single
Accuracy Grade:
0.1G
IP Rating:
IP65
Certification:
ISO
| Dynamic Properties | |
| Range(peak) | ±2000g |
| Sensitivity(25ºC) | 30pC/g (160Hz) |
| Frequency Response(±1dB) | 1-10,000Hz |
| Transverse Sensitivity Ratio | ≤5% |
| Electrical Properties | |
| Insulation resistance | >109 Ω |
| Capacitance | ~1200PF |
| Polarity | + |
| Environment Properties | |
| Operation Temp | -54ºC~+150ºC |
| Shock Resistance(peak) | ±2000 g |
| Temperature Response | Attached Temperature Curve |
| Physics Properties | |
| Structural Style | Cutting |
| Shell Material | 304 Stainless Steel |
| Output Mode | Top M5 |
| Installation | M5 |
| Piezoelectric Materials | PZT-5 |
| Weight | ~18g |
| Accessory | |
| Erection Bolt | M5 |
| cable | Double end M5 low noise shielded cable x 2m |
