Thread Type
NPT, G1/4, 1/4-18NPT, M12, 7/16-20unf
Wiring Type
Four-Wire
Measuring Medium
Liquid
IP Rating
IP67
Certification
ISO
Customized
Customized
Pressure Range
0~1MPa...200MPa
Temperature
-40~85 Degree Celsius
Measure Medium
Oil
Transport Package
Standard
Trademark
Sun-Moon
Origin
China
HS Code
9026209010
Production Capacity
30, 000 Piece/Year
Type:
Resistance Strain Gauge Pressure Sensors
Component:
SemiConductor Type
For:
Diffused Silicon Pressure Transmitter
Output Signal Type:
Digital Type
Production Process:
Normal Wirewound
Material:
Stainless Steel
SM25Y pressure transmitter is the high-performance products which transforms physical signal of pressure, differential pressure and level to standard signal via collecting cell sensor and digital processing circuit. The products adopts advanced specified integrated circuit digital technology to realize best uniformity of accuracy and signal. Each set of transmitter is ambient temperature compensated, ensured highest accuracy and lowest drift of transmitters in wide working temperature range.
| Items | Technical Parameters | Unit | |||
| SM25Y01 | SM25Y02 | SM25Y03 | SM25Y04 | ||
| Range | 0.1~100 | 0.3~200 | 0.1~100 | 0.3~200 | MPa |
| Output | 0~5V 1~5V 0~10mA 4~20mA 2~10kHZ | 0~5V 1~5V 0~10mA 4~20mA | 0~5V 4~20mA | 4~20mA | |
| Features | Three-wire system | Three-wire system Two-wire system | Intrinsically safe Two-wire system | ,Intrinsically safe explosion Shell, two-wire system | |
| Supply voltage | 9,12,15,24 | 12~48 | +12,24 | 24 | VDC |
| Insulation resistance | ≥ 2000 | MΩ | |||
| Operating Temperature Range | -40~+85 | ºC | |||
| Zero drift | 0.1~0.5 | %F·S/4h | |||
| Zero temperature drift | 0.1~0.5 | %F·S/10ºC | |||
| Sensitivity temperature drift | 0.1~0.5 | %F·S/10ºC | |||
| Ultimate Overload | 120 | %F·S | |||
