Model NO.
X165
Connection Mode
Double Wire
Current
2.8A
Contact Point
With Contact Point
Energy Exchanging Mechanism
Electromagnetic
Normal Impedance
4ohms
Frequency Range
50Hz-20kHz
Woofer/Tweeter Cone
Rubber+PP/Pei
Power Rating RMS
50W/150W
Magnet
Ferrite
Woofer/Tweeter Voice Coil
1 Inch /25.5mm
Norminal Diameter
6.5 in/166mm
Transport Package
Standard Epxort Carton
Specification
ferrite
Trademark
OEM
Origin
Ningbo China
HS Code
8518290000
Production Capacity
50, 000PCS/Month
Type:
Speaker
Speaker Design:
Woofer
Shape:
Barrel Type
Material:
Iron
Sound Frequency:
Low Pitch
Voltage:
12V
SPECIFICATION:
MODEL: X165
Nominal Diameter : 6.5 in/166mm
Nominal Impedance :4 Ohms
Frequency Response : 50-20000 Hz
Woofer/Tweeter voice Coil : 1 in/25.5mm
Woofer/Tweeter Cone : Rubber +PP/PEI
Overall Diameter : ¢165.5mm/6.51 inches
Mounting Cutout : ¢143mm/5.63 inches
Parameters:
Re/Ohms : 3.6ohms
FS(Hz)-Free Air Resonance : 60 Hz
Nominal Impedance : 4 ohms
Power Rating RMS/PEAK : 50W/150W
Qms : 3.43
Qes :0.595
Qts : 0.15
BL :5.35
MODEL: X165
Nominal Diameter : 6.5 in/166mm
Nominal Impedance :4 Ohms
Frequency Response : 50-20000 Hz
Woofer/Tweeter voice Coil : 1 in/25.5mm
Woofer/Tweeter Cone : Rubber +PP/PEI
Overall Diameter : ¢165.5mm/6.51 inches
Mounting Cutout : ¢143mm/5.63 inches
Parameters:
Re/Ohms : 3.6ohms
FS(Hz)-Free Air Resonance : 60 Hz
Nominal Impedance : 4 ohms
Power Rating RMS/PEAK : 50W/150W
Qms : 3.43
Qes :0.595
Qts : 0.15
BL :5.35
