Model NO.
E9500S
Brand
Zhme
Applicable Environment
Mountain Road
Certification
CE
Transport Package
Strong Carton Box, Optional Pallets
Specification
CE
Trademark
ZHME
Origin
Ningbo, China
HS Code
84253190
Production Capacity
6000PCS / Month
Type:
Electric Winch
Power Type:
Series Motor DC
Pull Direction:
Forward
Electric water proof Winch E 9500 S
1. All sealed high perference motor. Heavy duty series wound motor delives superior torque output and faste line speed, quality O-ring sealed for water resistant.
2. Zhme patent special oil seals with double lips fixed on drum supports for water proof.
3. Automatic, full load brake.
Rated line pull: 9500lbs (4310 kgs) Single line.
Motor: Seires Wound 6.0 HP/4.4 kw, 12V DC.
Gear Train: 3 Stage Planetary
Gear Ratio: 212: 1
Clutch Sliding Ring Gear
Braking action: Automatic in the drum
Fairlead: 4-way Roller Fairlead
Rope: Synthetic rope 9.5mmX26m
Drum size: 2.5"X 9.0" ( 63mm X 224mm)
Dimensions: 23"X6.7"X8.4"(552mm X 170mm X 214mm)
Mounting bolt pattern: 10" X 4.5" ( 254mm X 114.3mm)
Battery: Recommended 650 CCA minimum for winching 25 Square mm, 72" ( 1.83m)
N. W: 79lbs (36 kg)
Packing: 620mm X 200mm X 390mm / Carton
One 20 feet container covers 400 cartons, If need, Use pallets.
Accessories:
1. All sealed high perference motor. Heavy duty series wound motor delives superior torque output and faste line speed, quality O-ring sealed for water resistant.
2. Zhme patent special oil seals with double lips fixed on drum supports for water proof.
3. Automatic, full load brake.
Rated line pull: 9500lbs (4310 kgs) Single line.
Motor: Seires Wound 6.0 HP/4.4 kw, 12V DC.
Gear Train: 3 Stage Planetary
Gear Ratio: 212: 1
Clutch Sliding Ring Gear
Braking action: Automatic in the drum
Fairlead: 4-way Roller Fairlead
Rope: Synthetic rope 9.5mmX26m
Drum size: 2.5"X 9.0" ( 63mm X 224mm)
Dimensions: 23"X6.7"X8.4"(552mm X 170mm X 214mm)
Mounting bolt pattern: 10" X 4.5" ( 254mm X 114.3mm)
Battery: Recommended 650 CCA minimum for winching 25 Square mm, 72" ( 1.83m)
N. W: 79lbs (36 kg)
Packing: 620mm X 200mm X 390mm / Carton
One 20 feet container covers 400 cartons, If need, Use pallets.
Accessories:
| PERFORMANCE | ||||||||
| Line speed and motor current (first layer) | Line pull | Lbs | 0 | 2000 | 6000 | 8000 | 12000 | 15000 |
| Kgs | 0 | 907 | 2722 | 3629 | 5443 | 6804 | ||
| Line speed | FPM | 19.7 | 10.2 | 8.5 | 7.9 | 5.9 | 3.9 | |
| MPM | 6 | 3.1 | 2.6 | 2.4 | 1.8 | 1.2 | ||
| Motor current | Amps | 70 | 150 | 200 | 250 | 330 | 420 | |
