Construction Hoist SC100X100 Double Single Cage 1Ton Load for Sale
* If you have special requirement on power, please state it when order the consignment.
* We can produce the cage and lengthen the tie-in according to the size the customer requested.
* We can heighten the erection height according to the customer's request.
* "/" means the item does not exist.
Main technical data | Unit | Value |
Rated load | kg | 1000 |
Rated erection load | kg | 1000 |
Jib attachment rated load | kg | 300 |
Cage size | m | 3.0×1.3×2.5 |
Maximum lifting height | m | 250 |
Lifting speed | m/min | 33 |
Rated output | kW | 2×11 |
Voltage rating | V | 380/440 |
Rated frequency | Hz | 50/60 |
Rated current | A | 2×23.5 |
Power supply fuses | A | 63 |
Protective class | / | IP55 |
Load duration factor | / | FC-25% |
Safety device | m/s | 1.2 |
Enclosure weight | kg | 980 |
Cage weight | kg | 1750 |
Counterweight | kg | / |
Mast section weight | kg | 125/145 |
Mast section length | mm | 1508 |
