Model NO.
AA-GBL6C
HS Code
842542900
Production Capacity
100units/Month
AA4C Automatic 6 Cylinders Injectortester & cleaner
Integration of advanced control technology and environmental conceptsCleaning, test and simulation of Automotive injectors.
Multifunctionality: Direct flush, Reverse flush, Ultrasonic cleaning, On-vehicle cleaning, Spray test,Equilibrium test,Leakage test, Flow test,Automotive cleaning-test function.
Test 3 or 4 or 6 injectors in one time
Injector fuel distribution and delivery checking;
Multilanguage applicable including English,Spanish,Arabic,Russian.
LED display with clear menu and easy operation;
Wide models can be tested with stable performance and reliable data;
Liquid in tube drain back to tank automatically;
Separated ultrasonic bath(Installed in cabinet);
Optional:Special adapter for MONO & Side-feed injector;
Packed inside dolly when shipped,CBM save
Specifications
Power supply: AC220V/110V ±10%,50/60Hz;
Input power: 250W;
Ultrasonic cleaner power: 100W,25KHz;
Simulated RPM range: 10000rpm; step:50rpm;
Injection time: 0~600sec, step 1sec
Time range: 10000s(adjustable)Pulse width: 0-20ms; step 0.1 ms;
Test liquid tank volume: 4LTesting tube volume: 120ml
Dimensions:Carton62*53*74cm=0.243cbm
G.W.:45kg
Integration of advanced control technology and environmental conceptsCleaning, test and simulation of Automotive injectors.
Multifunctionality: Direct flush, Reverse flush, Ultrasonic cleaning, On-vehicle cleaning, Spray test,Equilibrium test,Leakage test, Flow test,Automotive cleaning-test function.
Test 3 or 4 or 6 injectors in one time
Injector fuel distribution and delivery checking;
Multilanguage applicable including English,Spanish,Arabic,Russian.
LED display with clear menu and easy operation;
Wide models can be tested with stable performance and reliable data;
Liquid in tube drain back to tank automatically;
Separated ultrasonic bath(Installed in cabinet);
Optional:Special adapter for MONO & Side-feed injector;
Packed inside dolly when shipped,CBM save
Specifications
Power supply: AC220V/110V ±10%,50/60Hz;
Input power: 250W;
Ultrasonic cleaner power: 100W,25KHz;
Simulated RPM range: 10000rpm; step:50rpm;
Injection time: 0~600sec, step 1sec
Time range: 10000s(adjustable)Pulse width: 0-20ms; step 0.1 ms;
Test liquid tank volume: 4LTesting tube volume: 120ml
Dimensions:Carton62*53*74cm=0.243cbm
G.W.:45kg
