HYZ4
Many Place
CE, ISO
Plastic
Adult
Air Breathing Apparatus
Field
4 Hour, 2 Hour
2.4L
480L
560mm× 370mm× 160mm
10kg
5-10 Days After Your Payment
1000 Sets Per Month
1 Set
Fob
Exported Package
SGS, ISO, CE
China
Product Description
Introduction of Isolated Positive Pressure Cylinder Oxygen Breathing Apparatus Respirator Price
HYZ4 isolated positive pressure oxygen breathing apparatus
Major parameters of Isolated Positive Pressure Cylinder Oxygen Breathing Apparatus Respirator Price
Effective protection time: 4h (medium labor intensity)
Rated operating pressure of oxygen cylinder: 20MPa
Volume of oxygen cylinder: 2.4L zmwm02
Oxygen volume: 480L
Volume of calcium hydroxide to fill: 2.1Kg
Overall dimension: 560mm× 370mm× 160mm
Weight: 10Kg (exclude calcium hydroxide and oxygen)
Purpose of Isolated Positive Pressure Cylinder Oxygen Breathing Apparatus Respirator Price
HYZ4 isolated positive pressure oxygen breathing apparatus Are mainly suitable for poisonous and harmful gas of coal mine, fire Fighting, chemical industry, tunnel, scientific research and high-rise Buildings, rescue and relief in anoxic disaster environment and Seek for expedition.
Main performance:
Brief introduction to positive pressure fire-fighting oxygen breathing
Apparatus of Isolated Positive Pressure Cylinder Oxygen Breathing Apparatus Respirator Price
HYZ4 isolated positive pressure oxygen breathing apparatus Meeting MT867-2000 standard that we research and develop fully Takes up advantages of similar products at home and abroad and Particularly reflects small volume, light weight, reliable performance And comfortable to adorn on product mix design combining the Physical truth of our country's ambulance corps. In addition, it's Suitable for ambulance members to be use under mine, tunnel and Strait conditions. Positive pressure oxygen breathing apparatus can Operate at any poisonous and anoxic surroundings and danger Zone. Traits and purpose of positive pressure oxygen breathing
Trait: HYZ4 isolated positive pressure oxygen breathing apparatus Is a new generation of product that is used for personal breathing Protection. Under the condition that is being isolated from outside World, it can ensure that supply quantity of oxygen matches human' S pulmonary perfectly. It has such traits as smooth cycling air circuit, Stable and sufficient air supply, timely following supply and Comfortable adorning etc. Small breathing resistance, small volume And weight, long protection time, high stability and reliability, simple Structure, convenient to dismantle and repair, being widely Accepted.
Images of Isolated Positive Pressure Cylinder Oxygen Breathing Apparatus Respirator Price
HYZ4 isolated positive pressure oxygen breathing apparatus
Major parameters of Isolated Positive Pressure Cylinder Oxygen Breathing Apparatus Respirator Price
Effective protection time: 4h (medium labor intensity)
Rated operating pressure of oxygen cylinder: 20MPa
Volume of oxygen cylinder: 2.4L zmwm02
Oxygen volume: 480L
Volume of calcium hydroxide to fill: 2.1Kg
Overall dimension: 560mm× 370mm× 160mm
Weight: 10Kg (exclude calcium hydroxide and oxygen)
Purpose of Isolated Positive Pressure Cylinder Oxygen Breathing Apparatus Respirator Price
HYZ4 isolated positive pressure oxygen breathing apparatus Are mainly suitable for poisonous and harmful gas of coal mine, fire Fighting, chemical industry, tunnel, scientific research and high-rise Buildings, rescue and relief in anoxic disaster environment and Seek for expedition.
Main performance:
| Model | ZYX30 | ZYX45 | ZYX60 | ZYX120 |
| Protect time | ≥30min | ≥40min | ≥60min | ≥120min |
| Capacity of oxygen bottle | 0.3L | 0.38L | 0.4L | 1.0L |
| Oxygen storage capacity | 56L | 80L | 140L | 240L |
| Inspiratory oxygen concentration | 25% | 25% | 25% | 25% |
| Inhaled carbon dioxide concentration | 2% | 2% | 2% | 2% |
| Quantitative supply of oxygen | 1.2L/min | 1.2L/min | 1.2L/min | 1.2L/min |
| Manual supply of oxygen supply | 60L/min | 60L/min | 60L/min | 60L/min |
| Cylinder filling pressure | 20Mpa | 20Mpa | 20Mpa | 20Mpa |
| Period of validity | 3-5 years | 3-5 years | 3-5 years | 3-5 years |
| Outline dimensions | 210*167*80mm | 225*177*90mm | 235*180*92mm | 285*205*100mm |
| weight | 1.8kg | 2.1kg | 2.4kg | 4.3kg |
Brief introduction to positive pressure fire-fighting oxygen breathing
Apparatus of Isolated Positive Pressure Cylinder Oxygen Breathing Apparatus Respirator Price
HYZ4 isolated positive pressure oxygen breathing apparatus Meeting MT867-2000 standard that we research and develop fully Takes up advantages of similar products at home and abroad and Particularly reflects small volume, light weight, reliable performance And comfortable to adorn on product mix design combining the Physical truth of our country's ambulance corps. In addition, it's Suitable for ambulance members to be use under mine, tunnel and Strait conditions. Positive pressure oxygen breathing apparatus can Operate at any poisonous and anoxic surroundings and danger Zone. Traits and purpose of positive pressure oxygen breathing
Trait: HYZ4 isolated positive pressure oxygen breathing apparatus Is a new generation of product that is used for personal breathing Protection. Under the condition that is being isolated from outside World, it can ensure that supply quantity of oxygen matches human' S pulmonary perfectly. It has such traits as smooth cycling air circuit, Stable and sufficient air supply, timely following supply and Comfortable adorning etc. Small breathing resistance, small volume And weight, long protection time, high stability and reliability, simple Structure, convenient to dismantle and repair, being widely Accepted.
Images of Isolated Positive Pressure Cylinder Oxygen Breathing Apparatus Respirator Price
